Advanced usages

Many real-world use case examples are available in the examples folder of the GitHub repository.

We also provide numerous boilerplates, such as YAML files for various integrations and database types. These are available in the misc/integrations folder.

This section only focuses on advanced usages and security tuning, see the settings section of the documentation to see all the available settings.

Use cases

Testing

To perform quick tests when multisite mode is enabled (and if you don't have the proper DNS entries set up for the domains) you can use curl with the HTTP Host header of your choice :

curl -H "Host: app1.example.com" http://ip-or-fqdn-of-server

If you are using HTTPS, you will need to play with SNI :

curl -H "Host: app1.example.com" --resolve example.com:443:ip-of-server https://example.com

Behind load balancer or reverse proxy

Real IP

When BunkerWeb is itself behind a load balancer or a reverse proxy, you need to configure it so it can get the real IP address of the clients. If you don't, the security features will block the IP address of the load balancer or reverse proxy instead of the client's one.

BunkerWeb actually supports two methods to retrieve the real IP address of the client :

Using the PROXY protocol
Using a HTTP header like X-Forwarded-For

The following settings can be used :

USE_REAL_IP : enable/disable real IP retrieval
USE_PROXY_PROTOCOL : enable/disable PROXY protocol support.
REAL_IP_FROM : list of trusted IP/network address allowed to send us the "real IP"
REAL_IP_HEADER : the HTTP header containing the real IP or special value proxy_protocol when using PROXY protocol

You will find more settings about real IP in the settings section of the documentation.

HTTP headerProxy protocol

We will assume the following regarding the load balancers or reverse proxies (you will need to update the settings depending on your configuration) :

They use the X-Forwarded-For header to set the real IP
They have IPs in the 1.2.3.0/24 and 100.64.0.0/10 networks

Web UILinuxDockerDocker autoconfKubernetesSwarm

Navigate to the Global config page, select the Real IP plugin and fill out the following settings :

Please note that it's recommended to restart BunkerWeb when you change settings related to real IP.

You will need to add the settings to the /etc/bunkerweb/variables.env file :

...
USE_REAL_IP=yes
REAL_IP_FROM=1.2.3.0/24 100.64.0.0/16
REAL_IP_HEADER=X-Forwarded-For
...

Please note that it's recommended to issue a restart instead of reload when configuring settings related to real IP :

sudo systemctl restart bunkerweb && \
sudo systemctl restart bunkerweb-scheduler

You will need to add the settings to the environment variables of both the BunkerWeb and scheduler containers:

bunkerweb:
  image: bunkerity/bunkerweb:testing
  ...
  environment:
    USE_REAL_IP: "yes"
    REAL_IP_FROM: "1.2.3.0/24 100.64.0.0/10"
    REAL_IP_HEADER: "X-Forwarded-For"
  ...
bw-scheduler:
  image: bunkerity/bunkerweb-scheduler:testing
  ...
  environment:
    USE_REAL_IP: "yes"
    REAL_IP_FROM: "1.2.3.0/24 100.64.0.0/10"
    REAL_IP_HEADER: "X-Forwarded-For"
  ...

Please note that if your container is already created, you will need to delete it and recreate it so the new environment variables will be updated.

You will need to add the settings to the environment variables of both the BunkerWeb and scheduler containers:

bunkerweb:
  image: bunkerity/bunkerweb:testing
  ...
  environment:
    USE_REAL_IP: "yes"
    REAL_IP_FROM: "1.2.3.0/24 100.64.0.0/10"
    REAL_IP_HEADER: "X-Forwarded-For"
  ...
bw-scheduler:
  image: bunkerity/bunkerweb-scheduler:testing
  ...
  environment:
    USE_REAL_IP: "yes"
    REAL_IP_FROM: "1.2.3.0/24 100.64.0.0/10"
    REAL_IP_HEADER: "X-Forwarded-For"
  ...

Please note that if your container is already created, you will need to delete it and recreate it so the new environment variables will be updated.

You will need to add the settings to the environment variables of both the BunkerWeb and scheduler pods.

Here is the corresponding part of your values.yaml file that you can use :

bunkerweb:
  extraEnvs:
    - name: USE_REAL_IP
      value: "yes"
    - name: REAL_IP_FROM
      value: "1.2.3.0/24 100.64.0.0/10"
    - name: REAL_IP_HEADER
      value: "X-Forwarded-For"
scheduler:
  extraEnvs:
    - name: USE_REAL_IP
      value: "yes"
    - name: REAL_IP_FROM
      value: "1.2.3.0/24 100.64.0.0/10"
    - name: REAL_IP_HEADER
      value: "X-Forwarded-For"

Deprecated

The Swarm integration is deprecated and will be removed in a future release. Please consider using the Docker autoconf integration instead.

More information can be found in the Swarm integration documentation.

You will need to add the settings to the environment variables of both the BunkerWeb and scheduler services:

bunkerweb:
  image: bunkerity/bunkerweb:testing
  ...
  environment:
    USE_REAL_IP: "yes"
    REAL_IP_FROM: "1.2.3.0/24 100.64.0.0/10"
    REAL_IP_HEADER: "X-Forwarded-For"
  ...
bw-scheduler:
  image: bunkerity/bunkerweb-scheduler:testing
  ...
  environment:
    USE_REAL_IP: "yes"
    REAL_IP_FROM: "1.2.3.0/24 100.64.0.0/10"
    REAL_IP_HEADER: "X-Forwarded-For"
  ...

Please note that if your service is already created, you will need to delete it and recreate it so the new environment variables will be updated.

Read carefully

Only use the PROXY protocol if you are sure that your load balancer or reverse proxy is sending it. If you enable it and it's not used, you will get errors.

We will assume the following regarding the load balancers or reverse proxies (you will need to update the settings depending on your configuration) :

They use the PROXY protocol v1 or v2 to set the real IP
They have IPs in the 1.2.3.0/24 and 100.64.0.0/10 networks

Web UILinuxDockerDocker autoconfKubernetesSwarm

Navigate to the Global config page, select the Real IP plugin and fill out the following settings :

Real IP settings (PROXY protocol) using web UI

Please note that it's recommended to restart BunkerWeb when you change settings related to real IP.

You will need to add the settings to the /etc/bunkerweb/variables.env file :

...
USE_REAL_IP=yes
USE_PROXY_PROTOCOL=yes
REAL_IP_FROM=1.2.3.0/24 100.64.0.0/16
REAL_IP_HEADER=proxy_protocol
...

Please note that it's recommended to issue a restart instead of reload when configuring settings related to proxy protocols :

sudo systemctl restart bunkerweb && \
sudo systemctl restart bunkerweb-scheduler

You will need to add the settings to the environment variables of both the BunkerWeb and scheduler containers:

bunkerweb:
  image: bunkerity/bunkerweb:testing
  ...
  environment:
    USE_REAL_IP: "yes"
    USE_PROXY_PROTOCOL: "yes"
    REAL_IP_FROM: "1.2.3.0/24 100.64.0.0/10"
    REAL_IP_HEADER: "proxy_protocol"
  ...
...
bw-scheduler:
  image: bunkerity/bunkerweb-scheduler:testing
  ...
  environment:
    USE_REAL_IP: "yes"
    USE_PROXY_PROTOCOL: "yes"
    REAL_IP_FROM: "1.2.3.0/24 100.64.0.0/10"
    REAL_IP_HEADER: "proxy_protocol"
  ...

Please note that if your container is already created, you will need to delete it and recreate it so the new environment variables will be updated.

You will need to add the settings to the environment variables of both the BunkerWeb and scheduler containers:

bunkerweb:
  image: bunkerity/bunkerweb:testing
  ...
  environment:
    USE_REAL_IP: "yes"
    USE_PROXY_PROTOCOL: "yes"
    REAL_IP_FROM: "1.2.3.0/24 100.64.0.0/10"
    REAL_IP_HEADER: "proxy_protocol"
  ...
...
bw-scheduler:
  image: bunkerity/bunkerweb-scheduler:testing
  ...
  environment:
    USE_REAL_IP: "yes"
    USE_PROXY_PROTOCOL: "yes"
    REAL_IP_FROM: "1.2.3.0/24 100.64.0.0/10"
    REAL_IP_HEADER: "proxy_protocol"
  ...

Please note that if your container is already created, you will need to delete it and recreate it so the new environment variables will be updated.

You will need to add the settings to the environment variables of both the BunkerWeb and scheduler pods.

Here is the corresponding part of your values.yaml file that you can use:

bunkerweb:
  extraEnvs:
    - name: USE_REAL_IP
      value: "yes"
    - name: USE_PROXY_PROTOCOL
      value: "yes"
    - name: REAL_IP_FROM
      value: "1.2.3.0/24 100.64.0.0/10"
    - name: REAL_IP_HEADER
      value: "proxy_protocol"
scheduler:
  extraEnvs:
    - name: USE_REAL_IP
      value: "yes"
    - name: USE_PROXY_PROTOCOL
      value: "yes"
    - name: REAL_IP_FROM
      value: "1.2.3.0/24 100.64.0.0/10"
    - name: REAL_IP_HEADER
      value: "proxy_protocol"

Deprecated

The Swarm integration is deprecated and will be removed in a future release. Please consider using the Docker autoconf integration instead.

More information can be found in the Swarm integration documentation.

You will need to add the settings to the environment variables of both the BunkerWeb and scheduler services.

bunkerweb:
  image: bunkerity/bunkerweb:testing
  ...
  environment:
    USE_REAL_IP: "yes"
    USE_PROXY_PROTOCOL: "yes"
    REAL_IP_FROM: "1.2.3.0/24 100.64.0.0/10"
    REAL_IP_HEADER: "proxy_protocol"
  ...
...
bw-scheduler:
  image: bunkerity/bunkerweb-scheduler:testing
  ...
  environment:
    USE_REAL_IP: "yes"
    USE_PROXY_PROTOCOL: "yes"
    REAL_IP_FROM: "1.2.3.0/24 100.64.0.0/10"
    REAL_IP_HEADER: "proxy_protocol"
  ...

Please note that if your service is already created, you will need to delete it and recreate it so the new environment variables will be updated.

Custom configurations

To customize and add custom configurations to BunkerWeb, you can take advantage of its NGINX foundation. Custom NGINX configurations can be added in different NGINX contexts, including configurations for the ModSecurity Web Application Firewall (WAF), which is a core component of BunkerWeb. More details about ModSecurity configurations can be found here.

Here are the available types of custom configurations:

http: Configurations at the HTTP level of NGINX.
server-http: Configurations at the HTTP/Server level of NGINX.
default-server-http: Configurations at the Server level of NGINX, specifically for the "default server" when the supplied client name doesn't match any server name in SERVER_NAME.
modsec-crs: Configurations applied before the OWASP Core Rule Set is loaded.
modsec: Configurations applied after the OWASP Core Rule Set is loaded, or used when the Core Rule Set is not loaded.
stream: Configurations at the Stream level of NGINX.
server-stream: Configurations at the Stream/Server level of NGINX.

Custom configurations can be applied globally or specifically for a particular server, depending on the applicable context and whether the multisite mode is enabled.

The method for applying custom configurations depends on the integration being used. However, the underlying process involves adding files with the .conf suffix to specific folders. To apply a custom configuration for a specific server, the file should be placed in a subfolder named after the primary server name.

Some integrations provide more convenient ways to apply configurations, such as using Configs in Docker Swarm or ConfigMap in Kubernetes. These options offer simpler approaches for managing and applying configurations.

Web UILinuxDockerDocker autoconfKubernetesSwarm

Navigate to the Configs page, click on Create new custom config, you can then choose if it's a global one or specific to a service, the configuration type and the configuration name :

Don't forget to click on the save button.

When using the Linux integration, custom configurations must be written to the /etc/bunkerweb/configs folder.

Here is an example for server-http/hello-world.conf :

location /hello {
  default_type 'text/plain';
  content_by_lua_block {
    ngx.say('world')
  }
}

Because BunkerWeb runs as an unprivileged user (nginx:nginx), you will need to edit the permissions :

chown -R root:nginx /etc/bunkerweb/configs && \
chmod -R 770 /etc/bunkerweb/configs

Now let's check the status of the Scheduler :

systemctl status bunkerweb-scheduler

If they are already running, we can reload it :

systemctl reload bunkerweb-scheduler

Otherwise, we will need to start it :

systemctl start bunkerweb-scheduler

When using the Docker integration, you have two choices for the addition of custom configurations :

Using specific settings *_CUSTOM_CONF_* as environment variables (recommended)
Writing .conf files to the volume mounted on /data of the scheduler

Using settings

The settings to use must follow the pattern <SITE>_CUSTOM_CONF_<TYPE>_<NAME> :

<SITE> : optional primary server name if multisite mode is enabled and the config must be applied to a specific service
<TYPE> : the type of config, accepted values are HTTP, DEFAULT_SERVER_HTTP, SERVER_HTTP, MODSEC, MODSEC_CRS, STREAM and SERVER_STREAM
<NAME> : the name of config without the .conf suffix

Here is a dummy example using a docker-compose file :

...
bw-scheduler:
  image: bunkerity/bunkerweb-scheduler:testing
  environment:
    - |
      CUSTOM_CONF_SERVER_HTTP_hello-world=
      location /hello {
        default_type 'text/plain';
        content_by_lua_block {
          ngx.say('world')
          }
      }
  ...

Using files

The first thing to do is to create the folders :

mkdir -p ./bw-data/configs/server-http

You can now write your configurations :

echo "location /hello {
    default_type 'text/plain';
    content_by_lua_block {
        ngx.say('world')
    }
}" > ./bw-data/configs/server-http/hello-world.conf

Because the scheduler runs as an unprivileged user with UID and GID 101, you will need to edit the permissions :

chown -R root:101 bw-data && \
chmod -R 770 bw-data

When starting the scheduler container, you will need to mount the folder on /data :

bw-scheduler:
  image: bunkerity/bunkerweb-scheduler:testing
  volumes:
    - ./bw-data:/data
  ...

When using the Docker autoconf integration, you have two choices for adding custom configurations :

Using specific settings *_CUSTOM_CONF_* as labels (easiest)
Writing .conf files to the volume mounted on /data of the scheduler

Using labels

Limitations using labels

When using labels with the Docker autoconf integration, you can only apply custom configurations for the corresponding web service. Applying http, default-server-http, stream or any global configurations (like server-http or server-stream for all services) is not possible : you will need to mount files for that purpose.

The labels to use must follow the pattern bunkerweb.CUSTOM_CONF_<TYPE>_<NAME> :

<TYPE> : the type of config, accepted values are SERVER_HTTP, MODSEC, MODSEC_CRS and SERVER_STREAM
<NAME> : the name of config without the .conf suffix

Here is a dummy example using a docker-compose file :

myapp:
  image: nginxdemos/nginx-hello
  labels:
    - |
      bunkerweb.CUSTOM_CONF_SERVER_HTTP_hello-world=
      location /hello {
        default_type 'text/plain';
        content_by_lua_block {
            ngx.say('world')
        }
        }
  ...

Using files

The first thing to do is to create the folders :

mkdir -p ./bw-data/configs/server-http

You can now write your configurations :

echo "location /hello {
    default_type 'text/plain';
    content_by_lua_block {
        ngx.say('world')
    }
}" > ./bw-data/configs/server-http/hello-world.conf

Because the scheduler runs as an unprivileged user with UID and GID 101, you will need to edit the permissions :

chown -R root:101 bw-data && \
chmod -R 770 bw-data

When starting the scheduler container, you will need to mount the folder on /data :

bw-scheduler:
  image: bunkerity/bunkerweb-scheduler:testing
  volumes:
    - ./bw-data:/data
  ...

When using the Kubernetes integration, custom configurations are managed using ConfigMap.

To keep it simple, you don't even need to use the ConfigMap with a Pod (e.g. as environment variable or volume) : the autoconf Pod is listening for ConfigMap events and will update the custom configurations when needed.

When creating a ConfigMap, you will need to add special labels :

bunkerweb.io/CONFIG_TYPE : must be set to a valid custom configuration type (http, server-http, default-server-http, modsec, modsec-crs, stream or server-stream)
bunkerweb.io/CONFIG_SITE : set to a server name to apply configuration to that specific server (optional, will be applied globally if unset)

Here is the example :

apiVersion: v1
kind: ConfigMap
metadata:
  name: cfg-bunkerweb-all-server-http
  annotations:
      bunkerweb.io/CONFIG_TYPE: "server-http"
data:
  myconf: |
    location /hello {
        default_type 'text/plain';
        content_by_lua_block {
            ngx.say('world')
        }
    }

Custom Extra Config

Since the 1.6.0-rc3 version, you can add/override settings using the bunkerweb.io/CONFIG_TYPE=settings annotation. Here is an example :

apiVersion: v1
kind: ConfigMap
metadata:
  name: cfg-bunkerweb-extra-settings
  annotations:
    bunkerweb.io/CONFIG_TYPE: "settings"
data:
  USE_ANTIBOT: "captcha" # multisite setting that will be applied to all services that do not override it
  USE_REDIS: "yes" # global setting that will be applied globally
  ...

Deprecated

The Swarm integration is deprecated and will be removed in a future release. Please consider using the Docker autoconf integration instead.

More information can be found in the Swarm integration documentation.

When using the Swarm integration, custom configurations are managed using Docker Configs.

To keep it simple, you don't even need to attach the Config to a service : the autoconf service is listening for Config events and will update the custom configurations when needed.

When creating a Config, you will need to add special labels :

bunkerweb.CONFIG_TYPE : must be set to a valid custom configuration type (http, server-http, default-server-http, modsec, modsec-crs, stream or server-stream)
bunkerweb.CONFIG_SITE : set to a server name to apply configuration to that specific server (optional, will be applied globally if unset)

Here is the example :

echo "location /hello {
    default_type 'text/plain';
    content_by_lua_block {
        ngx.say('world')
    }
}" | docker config create -l bunkerweb.CONFIG_TYPE=server-http my-config -

There is no update mechanism : the alternative is to remove an existing config using docker config rm and then recreate it.

Running many services in production

Global CRS

CRS plugins

When the CRS is loaded globally, CRS plugins are not supported. If you need to use them, you will need to load the CRS per service.

If you use BunkerWeb in production with a large number of services, and you enable the ModSecurity feature globally with CRS rules, the time required to load BunkerWeb configurations may become too long, potentially resulting in a timeout.

The workaround is to load the CRS rules globally rather than per service. This behavior is not enabled by default for backward compatibility reasons and because it has a drawback: if you enable global CRS rule loading, it will no longer be possible to define modsec-crs rules (executed before the CRS rules) on a per-service basis. However, this limitation can be bypassed by writing global modsec-crs exclusion rules like this:

SecRule REQUEST_FILENAME "@rx ^/somewhere$" "nolog,phase:4,allow,id:1010,chain"
SecRule REQUEST_HEADERS:Host "@rx ^app1\.example\.com$" "nolog"

You can enable the global CRS loading by setting USE_MODSECURITY_GLOBAL_CRS to yes.

Adjust max_allowed_packet for MariaDB/MySQL

It appears that the default value for the max_allowed_packet parameter in MariaDB and MySQL database servers is not sufficient when using BunkerWeb with a large number of services.

If you encounter errors like this, especially on the scheduler:

[Warning] Aborted connection 5 to db: 'db' user: 'bunkerweb' host: '172.20.0.4' (Got a packet bigger than 'max_allowed_packet' bytes)

You will need to increase the max_allowed_packet on your database server.

Persistence of bans and reports

By default, BunkerWeb stores bans and reports in a local Lua datastore. While simple and efficient, this setup means that data is lost when the instance is restarted. To ensure that bans and reports persist across restarts, you can configure BunkerWeb to use a remote Redis server.

Why Use Redis?

Redis is a powerful, in-memory data store commonly used as a database, cache, and message broker. It is highly scalable and supports a variety of data structures, including:

Strings: Basic key-value pairs.
Hashes: Field-value pairs within a single key.
Lists: Ordered collections of strings.
Sets: Unordered collections of unique strings.
Sorted Sets: Ordered collections with scores.

By leveraging Redis, BunkerWeb can persistently store bans, reports, and cache data, ensuring durability and scalability.

Enabling Redis Support

To enable Redis support, configure the following settings in your BunkerWeb configuration file:

# Enable Redis support
USE_REDIS=yes

# Redis server hostname or IP address
REDIS_HOST=<hostname>

# Redis server port number (default: 6379)
REDIS_PORT=6379

# Redis database number (default: 0)
REDIS_DATABASE=0

USE_REDIS: Set to yes to enable Redis integration.
REDIS_HOST: Specify the hostname or IP address of the Redis server.
REDIS_PORT: Specify the port number for the Redis server. Defaults to 6379.
REDIS_DATABASE: Specify the Redis database number to use. Defaults to 0.

If you require more advanced settings, such as authentication, SSL/TLS support, or Sentinel mode, refer to the Redis plugin settings documentation for detailed guidance.

Protect UDP/TCP applications

Experimental feature

This feature is not production-ready. Feel free to test it and report us any bug using issues in the GitHub repository.

BunkerWeb offers the capability to function as a generic UDP/TCP reverse proxy, allowing you to protect any network-based applications operating at least on layer 4 of the OSI model. Instead of utilizing the "classical" HTTP module, BunkerWeb leverages the stream module of NGINX.

It's important to note that not all settings and security features are available when using the stream module. Additional information on this can be found in the settings sections of the documentation.

Configuring a basic reverse proxy is quite similar to the HTTP setup, as it involves using the same settings: USE_REVERSE_PROXY=yes and REVERSE_PROXY_HOST=myapp:9000. Even when BunkerWeb is positioned behind a Load Balancer, the settings remain the same (with PROXY protocol being the supported option due to evident reasons).

On top of that, the following specific settings are used :

SERVER_TYPE=stream : activate stream mode (generic UDP/TCP) instead of http one (which is the default)
LISTEN_STREAM_PORT=4242 : the listening "plain" (without SSL/TLS) port that BunkerWeb will listen on
LISTEN_STREAM_PORT_SSL=4343 : the listening "ssl/tls" port that BunkerWeb will listen on
USE_UDP=no : listen for and forward UDP packets instead of TCP

For complete list of settings regarding stream mode, please refer to the settings section of the documentation.

multiple listening ports

Since the 1.6.0-rc2 version, BunkerWeb supports multiple listening ports for the stream mode. You can specify them using the LISTEN_STREAM_PORT and LISTEN_STREAM_PORT_SSL settings.

Here is an example :

...
LISTEN_STREAM_PORT=4242
LISTEN_STREAM_PORT_SSL=4343
LISTEN_STREAM_PORT_1=4244
LISTEN_STREAM_PORT_SSL_1=4344
...

DockerDocker autoconfSwarmKubernetesLinux

When using Docker integration, the easiest way of protecting existing network applications is to add the services in the bw-services network :

x-bw-api-env: &bw-api-env
  # We use an anchor to avoid repeating the same settings for all services
  API_WHITELIST_IP: "127.0.0.0/8 10.20.30.0/24"

services:
  bunkerweb:
    image: bunkerity/bunkerweb:testing
    ports:
      - "80:8080" # Keep it if you want to use Let's Encrypt automation when using http challenge type
      - "10000:10000" # app1
      - "20000:20000" # app2
    labels:
      - "bunkerweb.INSTANCE=yes"
    environment:
      <<: *bw-api-env
    restart: "unless-stopped"
    networks:
      - bw-universe
      - bw-services

  bw-scheduler:
    image: bunkerity/bunkerweb-scheduler:testing
    environment:
      <<: *bw-api-env
      BUNKERWEB_INSTANCES: "bunkerweb" # This setting is mandatory to specify the BunkerWeb instance
      SERVER_NAME: "app1.example.com app2.example.com"
      MULTISITE: "yes"
      USE_REVERSE_PROXY: "yes" # Will be applied to all services
      SERVER_TYPE: "stream" # Will be applied to all services
      app1.example.com_REVERSE_PROXY_HOST: "myapp1:9000"
      app1.example.com_LISTEN_STREAM_PORT: "10000"
      app2.example.com_REVERSE_PROXY_HOST: "myapp2:9000"
      app2.example.com_LISTEN_STREAM_PORT: "20000"
    volumes:
      - bw-storage:/data # This is used to persist the cache and other data like the backups
    restart: "unless-stopped"
    networks:
      - bw-universe

  myapp1:
    image: istio/tcp-echo-server:1.3
    command: [ "9000", "app1" ]
    networks:
      - bw-services

  myapp2:
    image: istio/tcp-echo-server:1.3
    command: [ "9000", "app2" ]
    networks:
      - bw-services

volumes:
  bw-storage:

networks:
  bw-universe:
    name: bw-universe
    ipam:
      driver: default
      config:
        - subnet: 10.20.30.0/24
  bw-services:
    name: bw-services

Before running the Docker autoconf integration stack on your machine, you will need to edit the ports :

services:
  bunkerweb:
    image: bunkerity/bunkerweb:testing
    ports:
      - "80:8080" # Keep it if you want to use Let's Encrypt automation when using http challenge type
      - "10000:10000" # app1
      - "20000:20000" # app2
...

Once the stack is running, you can connect your existing applications to the bw-services network and configure BunkerWeb with labels :

services:
  myapp1:
    image: istio/tcp-echo-server:1.3
    command: [ "9000", "app1" ]
    networks:
      - bw-services
    labels:
      - "bunkerweb.SERVER_NAME=app1.example.com"
      - "bunkerweb.SERVER_TYPE=stream"
      - "bunkerweb.USE_REVERSE_PROXY=yes"
      - "bunkerweb.REVERSE_PROXY_HOST=myapp1:9000"
      - "bunkerweb.LISTEN_STREAM_PORT=10000"

  myapp2:
    image: istio/tcp-echo-server:1.3
    command: [ "9000", "app2" ]
    networks:
      - bw-services
    labels:
      - "bunkerweb.SERVER_NAME=app2.example.com"
      - "bunkerweb.SERVER_TYPE=stream"
      - "bunkerweb.USE_REVERSE_PROXY=yes"
      - "bunkerweb.REVERSE_PROXY_HOST=myapp2:9000"
      - "bunkerweb.LISTEN_STREAM_PORT=20000"

networks:
  bw-services:
    external: true
    name: bw-services

Deprecated

The Swarm integration is deprecated and will be removed in a future release. Please consider using the Docker autoconf integration instead.

More information can be found in the Swarm integration documentation.

Before running the Swarm integration stack on your machine, you will need to edit the ports :

services:
  bunkerweb:
    image: bunkerity/bunkerweb:testing
    ports:
      # Keep it if you want to use Let's Encrypt automation when using http challenge type
      - published: 80
        target: 8080
        mode: host
        protocol: tcp
      # app1
      - published: 10000
        target: 10000
        mode: host
        protocol: tcp
      # app2
      - published: 20000
        target: 20000
        mode: host
        protocol: tcp
...

Once the stack is running, you can connect your existing applications to the bw-services network and configure BunkerWeb with labels :

services:

  myapp1:
    image: istio/tcp-echo-server:1.3
    command: [ "9000", "app1" ]
    networks:
      - bw-services
    deploy:
      placement:
        constraints:
          - "node.role==worker"
      labels:
        - "bunkerweb.SERVER_NAME=app1.example.com"
        - "bunkerweb.SERVER_TYPE=stream"
        - "bunkerweb.USE_REVERSE_PROXY=yes"
        - "bunkerweb.REVERSE_PROXY_HOST=myapp1:9000"
        - "bunkerweb.LISTEN_STREAM_PORT=10000"

  myapp2:
    image: istio/tcp-echo-server:1.3
    command: [ "9000", "app2" ]
    networks:
      - bw-services
    deploy:
      placement:
        constraints:
          - "node.role==worker"
      labels:
        - "bunkerweb.SERVER_NAME=app2.example.com"
        - "bunkerweb.SERVER_TYPE=stream"
        - "bunkerweb.USE_REVERSE_PROXY=yes"
        - "bunkerweb.REVERSE_PROXY_HOST=myapp2:9000"
        - "bunkerweb.LISTEN_STREAM_PORT=20000"

networks:
  bw-services:
    external: true
    name: bw-services

Experimental feature

At the moment, Ingresses does not support the stream mode. What we are doing here is a workaround to make it work.

Feel free to test it and report us any bug using issues in the GitHub repository.

Before running the Kubernetes integration stack on your machine, you will need to open the ports on your load balancer :

apiVersion: v1
kind: Service
metadata:
  name: lb
spec:
  type: LoadBalancer
  ports:
    - name: http # Keep it if you want to use Let's Encrypt automation when using http challenge type
      port: 80
      targetPort: 8080
    - name: app1
      port: 10000
      targetPort: 10000
    - name: app2
      port: 20000
      targetPort: 20000
  selector:
    app: bunkerweb

Once the stack is running, you can create your ingress resources :

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: ingress
  namespace: services
  annotations:
    bunkerweb.io/SERVER_TYPE: "stream" # Will be applied to all services
    bunkerweb.io/app1.example.com_LISTEN_STREAM_PORT: "10000"
    bunkerweb.io/app2.example.com_LISTEN_STREAM_PORT: "20000"
spec:
  rules:
    - host: app1.example.com
      http:
        paths:
          - path: / # This isn't used in stream mode but is required
            pathType: Prefix
            backend:
              service:
                name: svc-app1
                port:
                  number: 9000
    - host: app2.example.com
      http:
        paths:
          - path: / # This isn't used in stream mode but is required
            pathType: Prefix
            backend:
              service:
                name: svc-app2
                port:
                  number: 9000
---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: app1
  namespace: services
  labels:
    app: app1
spec:
  replicas: 1
  selector:
    matchLabels:
      app: app1
  template:
    metadata:
      labels:
        app: app1
    spec:
      containers:
        - name: app1
          image: istio/tcp-echo-server:1.3
          args: ["9000", "app1"]
          ports:
            - containerPort: 9000
---
apiVersion: v1
kind: Service
metadata:
  name: svc-app1
  namespace: services
spec:
  selector:
    app: app1
  ports:
    - protocol: TCP
      port: 9000
      targetPort: 9000
---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: app2
  namespace: services
  labels:
    app: app2
spec:
  replicas: 1
  selector:
    matchLabels:
      app: app2
  template:
    metadata:
      labels:
        app: app2
    spec:
      containers:
        - name: app2
          image: istio/tcp-echo-server:1.3
          args: ["9000", "app2"]
          ports:
            - containerPort: 9000
---
apiVersion: v1
kind: Service
metadata:
  name: svc-app2
  namespace: services
spec:
  selector:
    app: app2
  ports:
    - protocol: TCP
      port: 9000
      targetPort: 9000

You will need to add the settings to the /etc/bunkerweb/variables.env file :

...
SERVER_NAME=app1.example.com app2.example.com
MULTISITE=yes
USE_REVERSE_PROXY=yes
SERVER_TYPE=stream
app1.example.com_REVERSE_PROXY_HOST=myapp1.domain.or.ip:9000
app1.example.com_LISTEN_STREAM_PORT=10000
app2.example.com_REVERSE_PROXY_HOST=myapp2.domain.or.ip:9000
app2.example.com_LISTEN_STREAM_PORT=20000
...

Now let's check the status of the Scheduler :

systemctl status bunkerweb-scheduler

If they are already running, we can reload it :

systemctl reload bunkerweb-scheduler

Otherwise, we will need to start it :

systemctl start bunkerweb-scheduler

PHP

Experimental feature

At the moment, PHP support with BunkerWeb is still in beta and we recommend you use a reverse-proxy architecture if you can. By the way, PHP is not supported at all for some integrations like Kubernetes.

BunkerWeb supports PHP using external or remote PHP-FPM instances. We will assume that you are already familiar with managing that kind of services.

The following settings can be used :

REMOTE_PHP : Hostname of the remote PHP-FPM instance.
REMOTE_PHP_PATH : Root folder containing files in the remote PHP-FPM instance.
REMOTE_PHP_PORT : Port of the remote PHP-FPM instance (default is 9000).
LOCAL_PHP : Path to the local socket file of PHP-FPM instance.
LOCAL_PHP_PATH : Root folder containing files in the local PHP-FPM instance.

DockerDocker autoconfSwarmKubernetesLinux

When using the Docker integration, to support PHP applications, you will need to :

Mount your PHP files into the /var/www/html folder of BunkerWeb
Set up a PHP-FPM container for your application and mount the folder containing PHP files
Use the specific settings REMOTE_PHP and REMOTE_PHP_PATH as environment variables when starting BunkerWeb

If you enable the multisite mode, you will need to create separate directories for each of your applications. Each subdirectory should be named using the first value of SERVER_NAME. Here is a dummy example :

www
├── app1.example.com
│   └── index.php
├── app2.example.com
│   └── index.php
└── app3.example.com
    └── index.php

3 directories, 3 files

We will assume that your PHP apps are located into a folder named www. Please note that you will need to fix the permissions so BunkerWeb (UID/GID 101) can at least read files and list folders and PHP-FPM (UID/GID 33 if you use the php:fpm image) is the owner of the files and folders :

chown -R 33:101 ./www && \
find ./www -type f -exec chmod 0640 {} \; && \
find ./www -type d -exec chmod 0750 {} \;

You can now run BunkerWeb, configure it for your PHP application and also run the PHP apps :

x-bw-api-env: &bw-api-env
  # We use an anchor to avoid repeating the same settings for all services
  API_WHITELIST_IP: "127.0.0.0/8 10.20.30.0/24"

services:
  bunkerweb:
    image: bunkerity/bunkerweb:testing
    ports:
      - "80:8080/tcp"
      - "443:8443/tcp"
      - "443:8443/udp" # QUIC
    environment:
      <<: *bw-api-env
    volumes:
      - ./www:/var/www/html
    restart: "unless-stopped"
    networks:
      - bw-universe
      - bw-services

  bw-scheduler:
    image: bunkerity/bunkerweb-scheduler:testing
    environment:
      <<: *bw-api-env
      BUNKERWEB_INSTANCES: "bunkerweb" # This setting is mandatory to specify the BunkerWeb instance
      SERVER_NAME: "app1.example.com app2.example.com"
      MULTISITE: "yes"
      REMOTE_PHP_PATH: "/app" # Will be applied to all services thanks to the MULTISITE setting
      app1.example.com_REMOTE_PHP: "myapp1"
      app2.example.com_REMOTE_PHP: "myapp2"
      app3.example.com_REMOTE_PHP: "myapp3"
    volumes:
      - bw-storage:/data # This is used to persist the cache and other data like the backups
    restart: "unless-stopped"
    networks:
      - bw-universe

  myapp1:
    image: php:fpm
    volumes:
      - ./www/app1.example.com:/app
    networks:
      - bw-services

  myapp2:
    image: php:fpm
    volumes:
      - ./www/app2.example.com:/app
    networks:
      - bw-services

  myapp3:
    image: php:fpm
    volumes:
      - ./www/app3.example.com:/app
    networks:
      - bw-services

volumes:
  bw-storage:

networks:
  bw-universe:
    name: bw-universe
    ipam:
      driver: default
      config:
        - subnet: 10.20.30.0/24
  bw-services:
    name: bw-services

Multisite mode enabled

The Docker autoconf integration integration implies the use of multisite mode : protecting one PHP application is the same as protecting multiple ones.

When using the Docker autoconf integration, to support PHP applications, you will need to :

Mount your PHP files into the /var/www/html folder of BunkerWeb
Set up a PHP-FPM containers for your applications and mount the folder containing PHP apps
Use the specific settings REMOTE_PHP and REMOTE_PHP_PATH as labels for your PHP-FPM container

Since the Docker autoconf implies using the multisite mode, you will need to create separate directories for each of your applications. Each subdirectory should be named using the first value of SERVER_NAME. Here is a dummy example :

www
├── app1.example.com
│   └── index.php
├── app2.example.com
│   └── index.php
└── app3.example.com
    └── index.php

3 directories, 3 files

Once the folders are created, copy your files and fix the permissions so BunkerWeb (UID/GID 101) can at least read files and list folders and PHP-FPM (UID/GID 33 if you use the php:fpm image) is the owner of the files and folders :

chown -R 33:101 ./www && \
find ./www -type f -exec chmod 0640 {} \; && \
find ./www -type d -exec chmod 0750 {} \;

When you start the BunkerWeb autoconf stack, mount the www folder into /var/www/html for the Scheduler container :

x-bw-api-env: &bw-api-env
  # We use an anchor to avoid repeating the same settings for all services
  AUTOCONF_MODE: "yes"
  API_WHITELIST_IP: "127.0.0.0/8 10.20.30.0/24"

services:
  bunkerweb:
    image: bunkerity/bunkerweb:testing
    labels:
      - "bunkerweb.INSTANCE=yes"
    environment:
      <<: *bw-api-env
    volumes:
      - ./www:/var/www/html
    restart: "unless-stopped"
    networks:
      - bw-universe
      - bw-services

  bw-scheduler:
    image: bunkerity/bunkerweb-scheduler:testing
    environment:
      <<: *bw-api-env
      BUNKERWEB_INSTANCES: "" # We don't need to specify the BunkerWeb instance here as they are automatically detected by the autoconf service
      SERVER_NAME: "" # The server name will be filled with services labels
      MULTISITE: "yes" # Mandatory setting for autoconf
      DATABASE_URI: "mariadb+pymysql://bunkerweb:changeme@bw-db:3306/db" # Remember to set a stronger password for the database
    volumes:
      - bw-storage:/data # This is used to persist the cache and other data like the backups
    restart: "unless-stopped"
    networks:
      - bw-universe
      - bw-db

  bw-autoconf:
    image: bunkerity/bunkerweb-autoconf:testing
    depends_on:
      - bunkerweb
      - bw-docker
    environment:
      AUTOCONF_MODE: "yes"
      DATABASE_URI: "mariadb+pymysql://bunkerweb:changeme@bw-db:3306/db" # Remember to set a stronger password for the database
      DOCKER_HOST: "tcp://bw-docker:2375" # The Docker socket
    restart: "unless-stopped"
    networks:
      - bw-universe
      - bw-docker
      - bw-db

  bw-docker:
    image: tecnativa/docker-socket-proxy:nightly
    volumes:
      - /var/run/docker.sock:/var/run/docker.sock:ro
    environment:
      CONTAINERS: "1"
      LOG_LEVEL: "warning"
    networks:
      - bw-docker

  bw-db:
    image: mariadb:11
    environment:
      MYSQL_RANDOM_ROOT_PASSWORD: "yes"
      MYSQL_DATABASE: "db"
      MYSQL_USER: "bunkerweb"
      MYSQL_PASSWORD: "changeme" # Remember to set a stronger password for the database
    volumes:
      - bw-data:/var/lib/mysql
    networks:
      - bw-docker

volumes:
  bw-data:
  bw-storage:

networks:
  bw-universe:
    name: bw-universe
    ipam:
      driver: default
      config:
        - subnet: 10.20.30.0/24
  bw-services:
    name: bw-services
  bw-docker:
    name: bw-docker

You can now create your PHP-FPM containers, mount the correct subfolders and use labels to configure BunkerWeb :

services:
  myapp1:
      image: php:fpm
      volumes:
        - ./www/app1.example.com:/app
      networks:
        bw-services:
            aliases:
              - myapp1
      labels:
        - "bunkerweb.SERVER_NAME=app1.example.com"
        - "bunkerweb.REMOTE_PHP=myapp1"
        - "bunkerweb.REMOTE_PHP_PATH=/app"

  myapp2:
      image: php:fpm
      volumes:
        - ./www/app2.example.com:/app
      networks:
        bw-services:
            aliases:
              - myapp2
      labels:
        - "bunkerweb.SERVER_NAME=app2.example.com"
        - "bunkerweb.REMOTE_PHP=myapp2"
        - "bunkerweb.REMOTE_PHP_PATH=/app"

  myapp3:
      image: php:fpm
      volumes:
        - ./www/app3.example.com:/app
      networks:
        bw-services:
            aliases:
              - myapp3
      labels:
        - "bunkerweb.SERVER_NAME=app3.example.com"
        - "bunkerweb.REMOTE_PHP=myapp3"
        - "bunkerweb.REMOTE_PHP_PATH=/app"

networks:
  bw-services:
    external: true
    name: bw-services

Deprecated

The Swarm integration is deprecated and will be removed in a future release. Please consider using the Docker autoconf integration instead.

More information can be found in the Swarm integration documentation.

Multisite mode enabled

The Swarm integration integration implies the use of multisite mode : protecting one PHP application is the same as protecting multiple ones.

Shared volume

Using PHP with the Docker Swarm integration needs a shared volume between all BunkerWeb and PHP-FPM instances which is not covered in this documentation.

When using the Docker autoconf integration, to support PHP applications, you will need to :

Mount your PHP files into the /var/www/html folder of BunkerWeb
Set up a PHP-FPM containers for your applications and mount the folder containing PHP apps
Use the specific settings REMOTE_PHP and REMOTE_PHP_PATH as labels for your PHP-FPM container

Since the Swarm integration implies using the multisite mode, you will need to create separate directories for each of your applications. Each subdirectory should be named using the first value of SERVER_NAME. Here is a dummy example :

www
├── app1.example.com
│   └── index.php
├── app2.example.com
│   └── index.php
└── app3.example.com
    └── index.php

3 directories, 3 files

As an example, we will consider that you have a shared folder mounted on your worker nodes on the /shared endpoint.

Once the folders are created, copy your files and fix the permissions so BunkerWeb (UID/GID 101) can at least read files and list folders and PHP-FPM (UID/GID 33 if you use the php:fpm image) is the owner of the files and folders :

chown -R 33:101 /shared/www && \
find /shared/www -type f -exec chmod 0640 {} \; && \
find /shared/www -type d -exec chmod 0750 {} \;

When you start the BunkerWeb stack, mount the /shared/www folder into /var/www/html for the Scheduler container :

services:
  bunkerweb:
    image: bunkerity/bunkerweb:testing
    volumes:
      - /shared/www:/var/www/html
...

You can now create your PHP-FPM services, mount the correct subfolders and use labels to configure BunkerWeb :

services:
  myapp1:
      image: php:fpm
      volumes:
        - ./www/app1.example.com:/app
      networks:
        bw-services:
            aliases:
              - myapp1
      deploy:
        placement:
          constraints:
            - "node.role==worker"
        labels:
          - "bunkerweb.SERVER_NAME=app1.example.com"
          - "bunkerweb.REMOTE_PHP=myapp1"
          - "bunkerweb.REMOTE_PHP_PATH=/app"

  myapp2:
      image: php:fpm
      volumes:
        - ./www/app2.example.com:/app
      networks:
        bw-services:
            aliases:
              - myapp2
      deploy:
        placement:
          constraints:
            - "node.role==worker"
        labels:
          - "bunkerweb.SERVER_NAME=app2.example.com"
          - "bunkerweb.REMOTE_PHP=myapp2"
          - "bunkerweb.REMOTE_PHP_PATH=/app"

  myapp3:
      image: php:fpm
      volumes:
        - ./www/app3.example.com:/app
      networks:
        bw-services:
            aliases:
              - myapp3
      deploy:
        placement:
          constraints:
            - "node.role==worker"
        labels:
          - "bunkerweb.SERVER_NAME=app3.example.com"
          - "bunkerweb.REMOTE_PHP=myapp3"
          - "bunkerweb.REMOTE_PHP_PATH=/app"

networks:
  bw-services:
    external: true
    name: bw-services

PHP is not supported for Kubernetes

Kubernetes integration allows configuration through Ingress and the BunkerWeb controller only supports HTTP applications at the moment.

We will assume that you already have the Linux integration stack running on your machine.

By default, BunkerWeb will search for web files inside the /var/www/html folder. You can use it to store your PHP applications. Please note that you will need to configure your PHP-FPM service to get or set the user/group of the running processes and the UNIX socket file used to communicate with BunkerWeb.

First of all, you will need to make sure that your PHP-FPM instance can access the files inside the /var/www/html folder and also that BunkerWeb can access the UNIX socket file in order to communicate with PHP-FPM. We recommend to set a different user like www-data for the PHP-FPM service and to give the nginx group access to the UNIX socket file. Here is corresponding PHP-FPM configuration :

...
[www]
user = www-data
group = www-data
listen = /run/php/php-fpm.sock
listen.owner = www-data
listen.group = nginx
listen.mode = 0660
...

Don't forget to restart your PHP-FPM service :

systemctl restart php-fpm

If you enable the multisite mode, you will need to create separate directories for each of your applications. Each subdirectory should be named using the first value of SERVER_NAME. Here is a dummy example :

/var/www/html
├── app1.example.com
│   └── index.php
├── app2.example.com
│   └── index.php
└── app3.example.com
    └── index.php

3 directories, 3 files

Please note that you will need to fix the permissions so BunkerWeb (group nginx) can at least read files and list folders and PHP-FPM (user www-data but it might be different depending on your system) is the owner of the files and folders :

chown -R www-data:nginx /var/www/html && \
find /var/www/html -type f -exec chmod 0640 {} \; && \
find /var/www/html -type d -exec chmod 0750 {} \;

You can now edit the /etc/bunkerweb/variable.env file :

HTTP_PORT=80
HTTPS_PORT=443
DNS_RESOLVERS=9.9.9.9 8.8.8.8 8.8.4.4
API_LISTEN_IP=127.0.0.1
MULTISITE=yes
SERVER_NAME=app1.example.com app2.example.com app3.example.com
app1.example.com_LOCAL_PHP=/run/php/php-fpm.sock
app1.example.com_LOCAL_PHP_PATH=/var/www/html/app1.example.com
app2.example.com_LOCAL_PHP=/run/php/php-fpm.sock
app2.example.com_LOCAL_PHP_PATH=/var/www/html/app2.example.com
app3.example.com_LOCAL_PHP=/run/php/php-fpm.sock
app3.example.com_LOCAL_PHP_PATH=/var/www/html/app3.example.com

Now let's check the status of the Scheduler :

systemctl status bunkerweb-scheduler

If they are already running, we can reload it :

systemctl reload bunkerweb-scheduler

Otherwise, we will need to start it :

systemctl start bunkerweb-scheduler

IPv6

Experimental feature

This feature is not production-ready. Feel free to test it and report us any bug using issues in the GitHub repository.

By default, BunkerWeb will only listen on IPv4 addresses and won't use IPv6 for network communications. If you want to enable IPv6 support, you need to set USE_IPV6=yes. Please note that IPv6 configuration of your network and environment is out-of-the-scope of this documentation.

Docker / Autoconf / SwarmLinux

First of all, you will need to configure your Docker daemon to enable IPv6 support for containers and use ip6tables if needed. Here is sample configuration for your /etc/docker/daemon.json file :

{
  "experimental": true,
  "ipv6": true,
  "ip6tables": true,
  "fixed-cidr-v6": "fd00:dead:beef::/48"
}

You can now restart the Docker service to apply the changes :

systemctl restart docker

Once Docker is setup to support IPv6 you can add the USE_IPV6 setting and configure the bw-services for IPv6 :

services:
  bw-scheduler:
    image: bunkerity/bunkerweb-scheduler:testing
    environment:
      USE_IPv6: "yes"

...

networks:
  bw-services:
    name: bw-services
    enable_ipv6: true
    ipam:
      config:
        - subnet: fd00:13:37::/48
          gateway: fd00:13:37::1

...

You will need to add the settings to the /etc/bunkerweb/variables.env file :

...
USE_IPV6=yes
...

Let's check the status of BunkerWeb :

systemctl status bunkerweb

If they are already running, we can restart it :

systemctl restart bunkerweb

Otherwise, we will need to start it :

systemctl start bunkerweb

Security tuning

BunkerWeb offers many security features that you can configure with settings. Even if the default values of settings ensure a minimal "security by default", we strongly recommend you tune them. By doing so you will be able to ensure the security level of your choice but also manage false positives.

Other settings

This section only focuses on security tuning, see the settings section of the documentation for other settings.

Overview and order of the core security plugins

Security Mode

STREAM support

The Security Mode setting determines how BunkerWeb handles detected threats. This flexible feature allows you to choose between monitoring or actively blocking suspicious activity, depending on their specific needs.

detect: Logs potential threats without blocking access. This mode is useful for identifying and analyzing false positives in a safe, non-disruptive manner.
block (default): Actively blocks detected threats while logging incidents to prevent unauthorized access and protect your application.

Detect mode

Switching to detect mode can help you identify and resolve potential false positives without disrupting legitimate clients. Once these issues are addressed, you can confidently switch back to block mode for full protection.

CrowdSec Console integration

If you aren’t already familiar with CrowdSec Console integration, CrowdSec leverages crowdsourced intelligence to combat cyber threats. Think of it as the "Waze of cybersecurity"—when one server is attacked, other systems worldwide are alerted and protected from the same attackers. You can learn more about it here.

Through our partnership with CrowdSec, you can enroll your BunkerWeb instances into your CrowdSec Console. This means that attacks blocked by BunkerWeb will be visible in your CrowdSec Console alongside attacks blocked by CrowdSec Security Engines, giving you a unified view of threats.

Importantly, CrowdSec does not need to be installed for this integration (though we highly recommend trying it out with the CrowdSec plugin for BunkerWeb to further enhance the security of your web services). Additionally, you can enroll your CrowdSec Security Engines into the same Console account for even greater synergy.

Step #1: Create your CrowdSec Console account

Go to the CrowdSec Console and register if you don’t already have an account. Once done, note the enroll key found under "Security Engines" after clicking on "Add Security Engine":

Step #2: Get your BunkerNet ID

Activating the BunkerNet feature (enabled by default) is mandatory if you want to enroll your BunkerWeb instance(s) in your CrowdSec Console. Enable it by setting USE_BUNKERNET to yes.

For Docker, get your BunkerNet ID using:

docker exec my-bw-scheduler cat /var/cache/bunkerweb/bunkernet/instance.id

For Linux, use:

cat /var/cache/bunkerweb/bunkernet/instance.id

Step #3: Enroll your instance using the Panel

Once you have your BunkerNet ID and CrowdSec Console enroll key, order the free product "BunkerNet / CrowdSec" on the Panel. You may be prompted to create an account if you haven’t already.

You can now select the "BunkerNet / CrowdSec" service and fill out the form by pasting your BunkerNet ID and CrowdSec Console enroll key:

Step #4: Accept the new security engine on the Console

Then, go back to your CrowdSec Console and accept the new Security Engine:

Congratulations, your BunkerWeb instance is now enrolled in your CrowdSec Console!

Pro tip: When viewing your alerts, click the "columns" option and check the "context" checkbox to access BunkerWeb-specific data.

Monitoring and reporting

Monitoring (PRO)

STREAM support

The monitoring plugin lets you collect and retrieve metrics about BunkerWeb. By enabling it, your instance(s) will start collecting various data related to attacks, requests and performance. You can then retrieve them by calling the /monitoring API endpoint on regular basis or by using other plugins like the Prometheus exporter one.

List of features

Enable collection of various BunkerWeb metrics
Retrieve metrics from the API
Use in combination with other plugins (e.g. Prometheus exporter)
Dedicate UI page to monitor your instance(s)

List of settings

Setting	Default	Context	Multiple	Description
`USE_MONITORING`	`yes`	global	no	Enable monitoring of BunkerWeb.
`MONITORING_METRICS_DICT_SIZE`	`10M`	global	no	Size of the dict to store monitoring metrics.

Prometheus exporter (PRO)

STREAM support

The Prometheus exporter plugin adds a Prometheus exporter on your BunkerWeb instance(s). When enabled, you can configure your Prometheus instance(s) to scrape a specific endpoint on Bunkerweb and gather internal metrics.

We also provide a Grafana dashboard that you can import into your own instance and connect to your own Prometheus datasource.

Please note that the use of Prometheus exporter plugin requires to enable the Monitoring plugin (USE_MONITORING=yes)

List of features

Prometheus exporter providing internal BunkerWeb metrics
Dedicated and configurable port, listen IP and URL
Whitelist IP/network for maximum security

List of settings

Setting	Default	Context	Multiple	Description
`USE_PROMETHEUS_EXPORTER`	`no`	global	no	Enable the Prometheus export.
`PROMETHEUS_EXPORTER_IP`	`0.0.0.0`	global	no	Listening IP of the Prometheus exporter.
`PROMETHEUS_EXPORTER_PORT`	`9113`	global	no	Listening port of the Prometheus exporter.
`PROMETHEUS_EXPORTER_URL`	`/metrics`	global	no	HTTP URL of the Prometheus exporter.
`PROMETHEUS_EXPORTER_ALLOW_IP`	`127.0.0.0/8 10.0.0.0/8 172.16.0.0/12 192.168.0.0/16`	global	no	List of IP/networks allowed to contact the Prometheus exporter endpoint.

Reporting (PRO)

STREAM support

Monitoring plugin needed

This plugins requires the Monitoring Pro plugin to be installed and enabled with the USE_MONITORING setting set to yes.

The Reporting plugin provides a comprehensive solution for regular reporting of important data from BunkerWeb, including global statistics, attacks, bans, requests, reasons, and AS information. It offers a wide range of features, including automatic report creation, customization options, and seamless integration with monitoring pro plugin. With the Reporting plugin, you can easily generate and manage reports to monitor the performance and security of your application.

List of features

Regular reporting of important data from BunkerWeb, including global statistics, attacks, bans, requests, reasons, and AS information.
Integration with Monitoring Pro plugin for seamless integration and enhanced reporting capabilities.
Support for webhooks (classic, Discord, and Slack) for real-time notifications.
Support for SMTP for email notifications.
Configuration options for customization and flexibility.

List of settings

Setting	Default	Context	Description
`USE_REPORTING_SMTP`	`no`	global	Enable sending the report via email.
`USE_REPORTING_WEBHOOK`	`no`	global	Enable sending the report via webhook.
`REPORTING_SCHEDULE`	`weekly`	global	The frequency at which reports are sent.
`REPORTING_WEBHOOK_URLS`		global	List of webhook URLs to receive the report in Markdown (separated by spaces).
`REPORTING_SMTP_EMAILS`		global	List of email addresses to receive the report in HTML format (separated by spaces).
`REPORTING_SMTP_HOST`		global	The host server used for SMTP sending.
`REPORTING_SMTP_PORT`	`465`	global	The port used for SMTP. Please note that there are different standards depending on the type of connection (SSL = 465, TLS = 587).
`REPORTING_SMTP_FROM_EMAIL`		global	The email address used as the sender. Note that 2FA must be disabled for this email address.
`REPORTING_SMTP_FROM_USER`		global	The user authentication value for sending via the from email address.
`REPORTING_SMTP_FROM_PASSWORD`		global	The password authentication value for sending via the from email address.
`REPORTING_SMTP_SSL`	`SSL`	global	Determine whether or not to use a secure connection for SMTP.
`REPORTING_SMTP_SUBJECT`	`BunkerWeb Report`	global	The subject line of the email.

Information and behavior

case USE_REPORTING_SMTP is set to yes, the setting REPORTING_SMTP_EMAILS must be set.
case USE_REPORTING_WEBHOOK is set to yes, the setting REPORTING_WEBHOOK_URLS must be set.
Accepted values for REPORTING_SCHEDULE are daily, weeklyand monthly.
case no REPORTING_SMTP_FROM_USER and REPORTING_SMTP_FROM_PASSWORD are set, the plugin will try to send the email without authentication.
case REPORTING_SMTP_FROM_USER isn't set but REPORTING_SMTP_FROM_PASSWORD is set, the plugin will use the REPORTING_SMTP_FROM_EMAIL as the username.
case the job fails, the plugin will retry sending the report in the next execution.

Backup and restore

Backup S3 (PRO)

STREAM support

The Backup S3 tool seamlessly automates data protection, similar to the community backup plugin. However, it stands out by securely storing backups directly in an S3 bucket.

By activating this feature, you're proactively safeguarding your data's integrity. Storing backups remotely shields crucial information from threats like hardware failures, cyberattacks, or natural disasters. This ensures both security and availability, enabling swift recovery during unexpected events, preserving operational continuity, and ensuring peace of mind.

Information for Red Hat Enterprise Linux (RHEL) 8.9 users

If you are using RHEL 8.9 and plan on using an external database, you will need to install the mysql-community-client package to ensure the mysqldump command is available. You can install the package by executing the following commands:

MySQL/MariaDBPostgreSQL

Install the MySQL repository configuration package

sudo dnf install https://dev.mysql.com/get/mysql80-community-release-el8-9.noarch.rpm

Enable the MySQL repository

sudo dnf config-manager --enable mysql80-community

Install the MySQL client

sudo dnf install mysql-community-client

Install the PostgreSQL repository configuration package

dnf install "https://download.postgresql.org/pub/repos/yum/reporpms/EL-8-$(uname -m)/pgdg-redhat-repo-latest.noarch.rpm"

Install the PostgreSQL client
```
dnf install postgresql<version>
```

List of features

Automatic data backup to an S3 bucket
Flexible scheduling options: daily, weekly, or monthly
Rotation management for controlling the number of backups to keep
Customizable compression level for backup files

List of settings

Setting	Default	Context	Description
`USE_BACKUP_S3`	`no`	global	Enable or disable the S3 backup feature
`BACKUP_S3_SCHEDULE`	`daily`	global	The frequency of the backup
`BACKUP_S3_ROTATION`	`7`	global	The number of backups to keep
`BACKUP_S3_ENDPOINT`		global	The S3 endpoint
`BACKUP_S3_BUCKET`		global	The S3 bucket
`BACKUP_S3_DIR`		global	The S3 directory
`BACKUP_S3_REGION`		global	The S3 region
`BACKUP_S3_ACCESS_KEY_ID`		global	The S3 access key ID
`BACKUP_S3_ACCESS_KEY_SECRET`		global	The S3 access key secret
`BACKUP_S3_COMP_LEVEL`	`6`	global	The compression level of the backup zip file

Manual backup

To manually initiate a backup, execute the following command:

LinuxDocker

bwcli plugin backup_s3 save

docker exec -it <scheduler_container> bwcli plugin backup_s3 save

This command will create a backup of your database and store it in the S3 bucket specified in the BACKUP_S3_BUCKET setting.

You can also specify a custom S3 bucket for the backup by providing the BACKUP_S3_BUCKET environment variable when executing the command:

LinuxDocker

BACKUP_S3_BUCKET=your-bucket-name bwcli plugin backup_s3 save

docker exec -it -e BACKUP_S3_BUCKET=your-bucket-name <scheduler_container> bwcli plugin backup_s3 save

Specifications for MariaDB/MySQL

In case you are using MariaDB/MySQL, you may encounter the following error when trying to backup your database:

caching_sha2_password could not be loaded: Error loading shared library /usr/lib/mariadb/plugin/caching_sha2_password.so

To resolve this issue, you can execute the following command to change the authentication plugin to mysql_native_password:

ALTER USER 'yourusername'@'localhost' IDENTIFIED WITH mysql_native_password BY 'youpassword';

If you're using the Docker integration, you can add the following command to the docker-compose.yml file to automatically change the authentication plugin:

MariaDBMySQL

bw-db:
    image: mariadb:<version>
    command: --default-authentication-plugin=mysql_native_password
    ...

bw-db:
    image: mysql:<version>
    command: --default-authentication-plugin=mysql_native_password
    ...

Manual restore

To manually initiate a restore, execute the following command:

LinuxDocker

bwcli plugin backup_s3 restore

docker exec -it <scheduler_container> bwcli plugin backup_s3 restore

This command will create a temporary backup of your database in the S3 bucket specified in the BACKUP_S3_BUCKET setting and restore your database to the latest backup available in the bucket.

You can also specify a custom backup file for the restore by providing the path to it as an argument when executing the command:

LinuxDocker

bwcli plugin backup_s3 restore s3_backup_file.zip

docker exec -it <scheduler_container> bwcli plugin backup restore s3_backup_file.zip

In case of failure

Don't worry if the restore fails, you can always restore your database to the previous state by executing the command again as a backup is created before the restore:

LinuxDocker

bwcli plugin backup_s3 restore

docker exec -it <scheduler_container> bwcli plugin backup_s3 restore

Migration (PRO)

STREAM support

The Migration plugin revolutionizes BunkerWeb configuration transfers between instances with its user-friendly web interface, simplifying the entire migration journey. Whether you're upgrading systems, scaling infrastructure, or transitioning environments, this tool empowers you to effortlessly transfer settings, preferences, and data with unmatched ease and confidence. Say goodbye to cumbersome manual processes and hello to a seamless, hassle-free migration experience.

List of features

Effortless Migration: Easily transfer BunkerWeb configurations between instances without the complexities of manual procedures.
Intuitive Web Interface: Navigate through the migration process effortlessly with a user-friendly web interface designed for intuitive operation.
Cross-Database Compatibility: Enjoy seamless migration across various database platforms, including SQLite, MySQL, MariaDB, and PostgreSQL, ensuring compatibility with your preferred database environment.

Create a migration file

To manually create a migration file, execute the following command:

LinuxDocker

bwcli plugin migration create /path/to/migration/file

Create a migration file:

docker exec -it <scheduler_container> bwcli plugin migration create /path/to/migration/file

Copy the migration file to your local machine:

docker cp <scheduler_container>:/path/to/migration/file /path/to/migration/file

This command will create a backup of your database and store it in the backup directory specified in the command.

Specifications for MariaDB/MySQL

In case you are using MariaDB/MySQL, you may encounter the following error when trying to backup your database:

caching_sha2_password could not be loaded: Error loading shared library /usr/lib/mariadb/plugin/caching_sha2_password.so

To resolve this issue, you can execute the following command to change the authentication plugin to mysql_native_password:

ALTER USER 'yourusername'@'localhost' IDENTIFIED WITH mysql_native_password BY 'youpassword';

If you're using the Docker integration, you can add the following command to the docker-compose.yml file to automatically change the authentication plugin:

MariaDBMySQL

bw-db:
    image: mariadb:<version>
    command: --default-authentication-plugin=mysql_native_password
    ...

bw-db:
    image: mysql:<version>
    command: --default-authentication-plugin=mysql_native_password
    ...

Initialize a migration

To manually initialize a migration, execute the following command:

LinuxDocker

bwcli plugin migration migrate /path/to/migration/file

Copy the migration file to the container:

docker cp /path/to/migration/file <scheduler_container>:/path/to/migration/file

Initialize the migration:

docker exec -it <scheduler_container> bwcli plugin migration migrate /path/to/migration/file

This command seamlessly migrates your BunkerWeb data to precisely match the configuration outlined in the migration file.

Anti DDoS (PRO)

STREAM support

The Anti DDoS Plugin provides advanced protection against Distributed Denial of Service (DDoS) attacks by monitoring, analyzing, and filtering suspicious traffic in real-time.

By employing a sliding window mechanism, the plugin maintains an in-memory dictionary of request timestamps to detect abnormal traffic spikes from individual IP addresses. Based on the configured security mode, it can either block offending connections or log the suspicious activity for further review.

Features

Real-Time Traffic Analysis: Continuously monitors incoming requests to detect potential DDoS attacks.
Sliding Window Mechanism: Tracks recent request activity within a configurable time window.
Configurable Thresholds: Allows you to define the maximum number of suspicious requests per IP.
Advanced Blocking Logic: Evaluates both per-IP request counts and the number of distinct IPs exceeding the threshold.
Flexible Security Modes: Choose between immediate connection blocking or detection-only (logging) mode.
Optimized In-Memory Datastore: Ensures high-speed lookups and efficient metric tracking.
Automatic Housekeeping: Periodically clears outdated data to maintain optimal performance.

Configuration

Customize the plugin behavior using the following settings:

Setting	Default	Context	Multiple	Description
`USE_ANTIDDOS`	`no`	global	no	Enable or disable the Anti DDoS protection. Set to `"yes"` to activate the plugin.
`ANTIDDOS_METRICS_DICT_SIZE`	`10M`	global	no	Size of the in-memory datastore for tracking DDoS metrics (e.g., `10M`, `500k`).
`ANTIDDOS_THRESHOLD`	`100`	global	no	Maximum number of suspicious requests allowed per IP within the defined time window.
`ANTIDDOS_WINDOW_TIME`	`10`	global	no	Time window in seconds during which suspicious requests are tallied.
`ANTIDDOS_STATUS_CODES`	`429 403 444`	global	no	HTTP status codes considered suspicious and used to trigger anti-DDoS actions.
`ANTIDDOS_DISTINCT_IP`	`5`	global	no	Minimum number of distinct IPs that must exceed the threshold before enforcing the block mode.

Best Practices

Threshold Tuning: Adjust ANTIDDOS_THRESHOLD and ANTIDDOS_WINDOW_TIME based on your typical traffic patterns.
Status Code Review: Regularly update ANTIDDOS_STATUS_CODES to capture new or evolving suspicious behaviors.
Monitoring: Analyze logs and metrics periodically to fine-tune settings and improve overall protection.

User Manager (PRO)

The User Management Plugin offers a robust interface for administering user accounts within your system.

With this plugin, administrators can effortlessly create, update, and disable user accounts, manage user roles, toggle two-factor authentication (2FA), and view detailed user information such as last login timestamps and account statuses (active or inactive). Designed with security and ease-of-use in mind, this plugin simplifies routine user management tasks while ensuring compliance and auditability.

Features

User Account Operations: Create, edit, and delete user accounts with ease.
Role-Based Access Control: Assign and modify user roles to manage permissions and access levels.
2FA Management: Disable two-factor authentication based on administrative decisions.
Comprehensive User Insights: Monitor key user data including last login times, account creation dates, and active/inactive status.
Audit Logging: Maintain an audit trail for all user management actions for enhanced security and compliance.
